TAP AIR PORTUGAL
TAP28 · 183m · 253 km/h
RYANAIR
RYR3421 · 244m · 289 km/h
DELTA AIR LINES
DAL272 · 274m · 298 km/h · 98.6 dB
Lisbon · LPPT · Runway 03/21

My Lisbon terrace.
Every plane.
Captured.

An autonomous system on a Lisbon terrace tracks every aircraft on final approach and departure — combining ADS-B radar, acoustic sensors, and AI vision to document the skies above Humberto Delgado Airport.

3,700+ Flights tracked
1,168 Photos captured
99.9 dB Peak noise
Follow on Instagram How it works
scroll
TAP28 🇵🇹 TAP Air Portugal · A330-900neo · 183m · 253 km/h
RYR3421 🇮🇪 Ryanair · Boeing 737-800 · 244m · 289 km/h
DAL272 🇺🇸 Delta · Boeing 767-300 · 274m · 98.6 dB SPL
EZY35AB 🇬🇧 easyJet · Airbus A320 · 320m · 91 dB SPL
ACA813 🇨🇦 Air Canada · A330-300 · 587m · 92 dB SPL
TAP28 🇵🇹 TAP Air Portugal · A330-900neo · 183m · 253 km/h
RYR3421 🇮🇪 Ryanair · Boeing 737-800 · 244m · 289 km/h
DAL272 🇺🇸 Delta · Boeing 767-300 · 274m · 98.6 dB SPL
EZY35AB 🇬🇧 easyJet · Airbus A320 · 320m · 91 dB SPL
ACA813 🇨🇦 Air Canada · A330-300 · 587m · 92 dB SPL
The system

Automated from
detection to post

Three layers of technology working in real time, 24 hours a day, from a residential terrace in Lisbon directly under the final approach path.

01 📡
Detect

ADS-B transponder data is received in real time — altitude, speed, heading, callsign, airline. Cross-referenced with acoustic sensors measuring noise levels in dB SPL.

RTL-SDR ADS-B dump1090 dB meter
02 👁
Capture

A 4K dual-lens camera locks onto the aircraft. YOLO neural network validates the frame quality. Claude AI analyzes the image and generates the caption — aircraft type, livery, context.

Reolink 4K YOLO v8 RTSP Claude AI
03 ✦
Publish

The best frame is automatically published to Instagram with a complete caption — callsign, airline, altitude, speed, noise level. Zero human intervention required.

Raspberry Pi 4 Cloudinary Meta Graph API
Latest captures

Live from the terrace

System active
📷 Full photo archive access

Every aircraft captured since May 3 — high-res, timestamped, with full ADS-B data. Available for researchers, enthusiasts and institutions.

Contact us →
By the numbers

The data
speaks for itself

3,700+
Flights tracked
Since May 3, 2026
1,168
Photos captured
By AI · Zero human trigger
99.9 dB
Peak noise recorded
TAP30BC · 244m overhead
Sensor limit · upgraded sensor incoming
—
Flights over 95 dB
Since May 3, 2026
Acoustic monitoring

Noise data
for everyone

Every flight is measured in real time. We record peak SPL levels, duration, and frequency — building a continuous acoustic map of what it means to live under the final approach path to LPPT.

Residents, ANAC & Researchers
Acoustic

Continuous log with timestamps, callsigns, dB levels and infraction records — structured for regulatory review or noise impact studies.

Visual

High-res photo archive of every aircraft captured since May 3 — timestamped and matched with full ADS-B data.

Request data access →
Average noise by hour — dB SPL · Today · indicative · sensor max 99.9 dB
0h3h6h9h12h15h18h21h23h
99.9 dB
Peak today
90.2 dB
Daily average
530
Flights today
9h
Rush hour
Night restrictions · ANAC

Warning
Zone

ANAC strictly regulates night operations at LPPT. Aircraft exceeding 98.9 EPNdB are prohibited between 00:00–06:00. We track every potential violation in real time.

🚫
Curfew 00:00–06:00
Max 91 movements/week · 26/day. No scheduled flights during night period.
🔇
Noisy Aircraft Ban
Aircraft >98.9 EPNdB (Levels 8 & 16) strictly prohibited at night.
⚠️
Level 2 Restriction
93–95.9 EPNdB aircraft: only 00:00–00:30 and 05:00–06:00.
🛑
Reverse Thrust Banned
Landing reverse thrust is strictly forbidden except in emergencies.
Night movements · this week
—
Limit: 91/week ·
Critical violations
—
>98.9 dB · 00:00–06:00 · strictly banned
Level 2 violations
—
93–95.9 dB · outside 00:30–05:00 window
Last incident detected —
—
—
—
dB SPL
